DUTCH CONE PENETROMETER RS-210 – Manual Sondir Test Set (ASTM D-3441)

DUTCH CONE PENETROMETER RS-210
The RS-210 is a manually operated Sondir (Dutch Cone Penetrometer) system designed to evaluate cone resistance and friction resistance in soil layers. Built with durable components and conforming to ASTM D-3441, this set is ideal for geotechnical field investigations.

Set Includes:

• Press-In Apparatus – Steel frame, manually operated, 2 tons capacity – 1 set

• Sounding Rod – Machined steel, Ø32 mm, tapered thread, 1 m length – 20 pcs

• Plunger Rod – Round bar, Ø15 mm, 1 m length – 20 pcs

• Adaptor – 1 pc

Push-In Components:

• Push Adaptor – 1 pc

• Push Head – 1 pc

• Spiral Anchor – 1 pc

• Spiral Rod – 1 pc

• T-Piece – Machined steel, welded – 1 pc

• Mantled Cone – Hardened precision steel, tapered thread – 1 set

• Friction Cone – Hardened precision steel, with friction jacket – 1 set

Wrench & Tool Set Includes:

• Pipe wrench (2), adjustable wrench (1), spanner wrench (1)

• Allen key (1), screwdriver (1), oil can (1), steel brush (1), piston wrench (1)

• Seal tape (2), O-rings (2), carrying box – 1 set

Additional Components:

• Fasten Press – 1 pc

• Long Fasten Press (1.5 m height, 25 cm width) – 2 pcs

• Manometer –

  • 60 kg/cm² capacity – 1 pc

  • 500 kg/cm² capacity – 1 pc

Standard: ASTM D-3441
