DUTCH CONE PENETROMETER RS-230 – 120 kN (10 Ton) Hydraulic Sondir Set
Rp100.000
Heavy-duty hydraulic cone penetrometer system with 120 kN (10 ton) capacity. Designed for measuring cone resistance and friction resistance of soil layers in demanding geotechnical field investigations.
DUTCH CONE PENETROMETER RS-230
The RS-230 is a powerful 10-ton hydraulic Dutch Cone Penetrometer set engineered for advanced soil penetration testing. Suitable for high-load conditions, it provides accurate evaluation of cone and sleeve friction resistance in accordance with geotechnical standards.
Set Includes:
-
Hydraulic Driving Appliance – Steel construction, hydraulic operated, 120 kN capacity – 1 unit
-
Engine Pump / Gasoline Engine – Hydraulic, double action – 1 unit
-
Sounding Rod + Plunger – Machined steel, Ø36 mm, 1 m length – 20 sets
-
Push and Pull Adaptor – 1 set
-
Spiral Anchor – 4 pcs
-
Spiral Rod – Machined steel, 1.5 m – 1 pc
-
T-Piece – Machined steel, welded – 1 pc
-
Mantled Cone – Hardened precision steel, tapered thread – 1 set
-
Friction Cone – Precision machined steel, with friction jacket – 1 set
Accessories & Tools:
-
Fasten Press, Beam Canal – 2 pcs
-
Wrench Set Includes:
Pipe wrench (2), adjustable wrench (1), spanner wrench (1),
Allen key (1), screwdriver (1), oil can (1), steel brush (1),
Piston wrench (1), seal tape (2), oil seals (2), carrying box – 1 set -
Manometers:
250 kg/cm² capacity – 1 pc
1000 kg/cm² capacity – 1 pc
Capacity: 120 kN (10 Ton)
